TP-Link Archer AX4400 Wi-Fi 6 Router
Say goodbye to Wi-Fi dead zones! The TP-Link Archer AX4400 is here to revolutionize your home network. With its lightning-fast 4400Mbps speed, enjoy seamless browsing, streaming, downloading, and gaming from every corner of your house.
Connect over 200 devices simultaneously with its 3.8 Gbps ultra-fast connection, supported by MU-MIMO for smooth heavy data traffic. OFDMA quadruples your throughput, ensuring each device gets uninterrupted Wi-Fi.
Featuring OneMesh, effortlessly cover your smart home. Whether in the basement or backyard, stay connected everywhere.
Features:
- • Dual-Band gigabit Wi-Fi 6 for seamless 8K streaming
- • Connect 200+ devices simultaneously
- • Beamforming 6 antennas for extensive coverage
- • Premium security with TP-Link's HomeShield
- • Added network and IoT protection
- • 3.0 USB port for easy media sharing and private cloud building
- • Easy to set up, easier to use with Tether app
- • Enjoy faster speeds, higher capacity and lesser lags
Specifications:
WIRELESS
Standards: Wi-Fi 6, IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2.4 GHz
Wi-Fi Speeds: AX5400, 5 GHz: 3843 Mbps (802.11ax, HE160), 2.4 GHz: 574 Mbps (802.11ax)
Wi-Fi Range:
3 Bedroom Houses
6 ¡Á Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand Wi-Fi range
High-Power FEM
Improves transmission power to strengthen signal coverage
4T4R
Multiple streams in the same band strengthen the fault tolerance in transmission
Wi-Fi Capacity:
High
Dual-Band
Allocate devices to different bands for optimal performance
4¡Á4 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
6 Streams
Connect your devices to more bandwidth
Working Modes: Router Mode, Access Point Mode
HARDWARE
Processor: Powerful CPU
Ethernet Ports: 1¡Á Gigabit WAN Ports, 4 x Gigabit LAN Ports, Static Link Aggregation (LAG) available with 2 x LAN Ports
USB Support: 1¡Á USB 3.0 Port, Supported Partition Formats - NTFS, exFAT, HFS+, FAT32,
Supported Functions - Apple Time Machine, FTP Server, Media Server, Samba Server
Buttons: Wi-Fi On/Off Button, Power On/Off Button, LED On/Off Button, WPS Button, Reset Button
Power: 12 V 2.5 A
SECURITY
Wi-Fi Encryption: WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x)
Network Security: SPI Firewall, Access Control, IP & MAC Binding, Application Layer, Gateway
HomeShield Security: Real-time IoT Protection, Malicious Site Blocker, Intrusion Prevention System, DDoS Attack Prevention, Home Network Scanner
Guest Network: 1¡Á 5 GHz Guest Network, 1¡Á 2.4 GHz Guest Network
VPN Server: OpenVPN, PPTP
SOFTWARE
Protocols: IPv4, IPv6
Service Kits: HomeShield
OneMesh : OneMesh Supported, Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh helps you create a more flexible network that covers your entire home with TP-Link OneMesh products.
Parental Controls: HomeShield Parental Controls, Professional Content Filter Library, Family Time, Bedtime, Off Time, Time Rewards, Family Online Time Ranking, Pause the Internet, Weekly and Monthly Reports
WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
Quality of Service: QoS by Device
Cloud Service: Auto Firmware Upgrade, TP-Link ID, DDNS
NAT Forwarding: Port Forwarding, Port Triggering, DMZ, UPnP, Virtual Server
IPTV: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
DHCP: Address Reservation, DHCP Client List, Server
DDNS: TP-Link, NO-IP, DynDNS
Management: Tether App, Webpage
OTHERS
Dimensions (W¡ÁD¡ÁH) 10.3 ¡Á 5.7 ¡Á 2.0 in
System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser, Cable or DSL Modem (if needed), Subscription with an internet service provider (for internet access)
Certifications: FCC, CE, RoHS
Environment:
Operating Temperature: 0¡æ~40¡æ (32¨H ~104¨H)
Storage Temperature: -40¡æ~70¡æ (-40¨H ~158¨H)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
TEST DATA
Wi-Fi Transmission Power:
CE:
<20dBm{2.4GHz}
<23dBm{5.15GHz~5.35GHz}
<30dBm{5.47GHz~5.725GHz}
FCC:
<24dBm{5.25GHz~5.35GHz&5.47GHz~5.725GHz }
<30dBm{2.4GHz & 5.15GHz~5.25GHz&5.725GHz~5.825GHz }
Wi-Fi Reception Sensitivity:
2.4GHz:
11ac VHT20 MCS0:-94.5dBm
11ac VHT20 MCS8:-72.5dBm
11ac VHT40 MCS0:-92.5dBm
11ac VHT40 MCS9:-69.5dBm
11ax HE20 MCS0:-95dBm
11ax HE20 MCS11:-64.5dBm
11ax HE40 MCS0:-92.5dBm
11ax HE40 MCS11:-62dBm
5GHz:
11ac VHT20 MCS0:-97dBm
11ac VHT20 MCS8:-74dBm
11ac VHT40 MCS0:-95dBm
11ac VHT40 MCS9:-70dBm
11ac VHT80 MCS0:-91.5dBm
11ac VHT80 MCS9:-66dBm
11ac VHT160 MCS0:-86dBm
11ac VHT160 MCS9:-61dBm
11ax HE20 MCS0:-95dBm
11ax HE20 MCS11:-64dBm
11ax HE40 MCS0:-91.5dBm
11ax HE40 MCS11:-62dBm
11ax HE80 MCS0:-88dBm
11ax HE80 MCS11:-58dBm
11ax HE160 MCS0:-85.5dBm
11ax HE160 MCS11:-55dBm
What's in the Box:
1 x Wi-Fi Router Archer AX4400
1 x Power Adapter
1 x RJ45 Ethernet Cable
1 x Quick Installation Guide
The TP-Link Archer AX4400 Wi-Fi 6 Router is perfect for families and home users who want a seamless and high-speed internet experience. With dimensions of 10.3 x 5.7 x 2.0 inches, it's compact and easy to place. Use it at home to stream 8K videos, play online games, and connect all your devices without any lags. Whether you're in the living room, bedroom, or even the backyard, enjoy a strong and stable Wi-Fi connection.
